ANSI #100-8 Roller Chain

  • Categories: Multiple Strand Roller Chains
  • Brand: HXST-Drive
  • Model: ANSI 100-8 Roller Chain
  • Material: Carbon Steel
  • Color: Natural
  • Surface Treatment: Shot Peening /Heat Treatment/Plating/Lubrication
  • Accuracy: High Precision Roller Chain
  • Quality: Durable Roller Chain
  • Interchangeability: Directly Interchangeable With Other Brands
  • +86 15336786278
    jake@hxstdrive.com
    • Product Introduction

    Product Introduction


    裁剪旋转 (7)_compressed.jpeg

    About #100-8 Multiple Roller Chain

    ANSI #60-8 roller chain is an 8-strand heavy-duty roller chain manufactured to ANSI standard. It features precision machined rollers, pins and link plates made of high-strength alloy steel with heat treatment for great wear resistance and fatigue strength.

    This multi-strand design delivers high tensile strength and stable power transmission under heavy loads. It is widely applied in heavy machinery, mining equipment, conveyor systems and industrial transmission devices. Strict quality control ensures consistent performance and long service life. Custom options like special surface treatment and attachments are available to meet different working conditions.


    ANSI #100-8 Multiple Roller Chains  Dimension



  • Pitch (P): 31.75mm

  • Roller diameter (d1): 19.05mm

  • Width between inner plates (b1): 18.9mm

  • Pin diameter (d2): 9.53mm

  • Pin length (L): 290.8mm

  • Pin length (Lc): 295.1mm

  • Inner plate depth (h2): 30mm

  • Plate thickness (T): 4mm

  • Transverse pitch (Pt): 35.76mm
