Drop Forged Rivetless Chain_Shengzhou Hongxin Transmission (HXST) Co., Ltd.

裁剪旋转 (6)_compressed.jpeg

British system series	Chain No.	Referenced pitch P (mm)	Diameter of pin d2 (mm)	Length of pin (mm)	Standard measurement length (min/max) (mm)	Number of pitch of standard measurement length	Side corner O (°)	Width of sidebar h2 (mm)	Tensile strength (KN)
										British system series	X348	76.6	12.7	47.0	3050.5/3095.2	40	9	27.0	98.0	2.7
											X458	102.4	16.0	58.0	3063.1/3090.2	30	9	35.0	187.0	5.2
468H	102.4	19.5	84.1	3063.1/3090.2	30	9	47.8	311.7	11.5
X678	153.2	22.3	77.0	3055.1/3082.8	20	7	51.6	318.0	9.5
698	153.2	28.0	95.3	3055.1/3082.8	20	7	60.0	515.0	17.0
698H	152.4	39.0	154.0	3039.2/3066.6	20	7	72.0	1078.0	37.7
